Parameter Description
ON Turn on the “HEAD OPEN” sensor
OFF Turn off the “HEAD OPEN” sensor
Example
SET HEAD ON
SET HEAD OFF
SET COM1
Description
This setting defines communication parameters for printer serial port.
Syntax
SET COM1 baud, parity, data, stop
Parameter Description
baud Baud rate, available baud rates are as listed :
24: 2400 bps
48: 4800 bps
96: 9600 bps
19: 19200 bps
Parity Parity check
N: None parity check
E: Even parity check
O: Odd parity check
data Data bit
8: 8 bits data
7: 7 bits data
stop Stop bit
1: 1 stop bit
2: 2 stop bits
Example
The parallel port is used to setup the printer serial port in this example by
MS-DOS mode. C:\>COPY CON LPT1<ENTER>
SET COM1 19,N,8,1<ENTER>
<CTRL><Z><ENTER>
C:\>
Note: <ENTER> stands for PC keyboard “ENTER” key.
<CTRL><Z> means to hold PC keyboard “CTRL” key then press
PC keyboard <Z> key.
