Parts
313527ZAD 55
24 VDC and 100-240 VAC Power Supply
Parts
Parts designated n/a are not available separately.
Ref.
No. Description
(24 VDC) (100-240 VAC)
Qty.S20 D60
D200s
D200 S20 D60
D200s
D200
151 ENCLOSURE, power
supply assy
n/a n/a n/a n/a n/a n/a 1
152 WASHER, lock
100016 100016 100016 100016 100016 100016 6
153 SCREW, cap, sch 101682 101682 101682 101682 101682 101682 6
154 MODULE, assembly,
24V
255649 255649 255649
1
154a POWER SUPPLY,
100-240 VAC
15M293 15M293 15M293 1
155 SCREW, mach, pan
head
110637 110637 110637 2
156 SCREW, self-tapping 101845 101845 101845 6
157 SWITCH, power, 24 VDC n/a n/a n/a 1
157a SWITCH, power, 120V 121254 121254 121254 1
158 COVER, switch mount n/a n/a n/a 1
159 SCREW, countersunk,
6-32 x 0.38
121255 121255 121255 121255 121255 121255 6
160 COVER, power n/a n/a n/a 1
161 GROMMET 112738 112738 112738 1
162▲ LABEL, caution 196548 196548 196548 1
163 CABLE, power,
female,.8M
255673 255673 255673 1
164 WASHER, lock 100272 100272 100272 2
165 FUSE, 250V / 1.2A 121261 121261 121261 2
166 SCREW, grounding 111593 111593 111593 1
167▲ LABEL, symbol, ground 186620 186620 186620 1
168 BRACKET, power sup-
ply support
n/a n/a n/a n/a
169 PLATE, switch mount n/a n/a n/a 1
