Models
6 313527ZAD
Models
Check the identification plate (ID) for the 6-digit part number of the supply system. Use the following matrix to define
the construction of the supply system, based on the six digits. For example, Part No. CM14BA represents a
Check-Mate supply system (CM), a carbon steel Check-Mate 100 MaxLife
®
displacement pump with an NXT 2200
air motor with remote DataTrak (pump code 14), a 3 in. dual post ram with integrated air controls (B) and a 55-gallon,
uncoated platen with a neoprene seal (A).
To order replacement parts, see Parts section in manual 313527. The digits in the matrix on the next page do not
correspond to the Ref. Nos. in the Parts drawings and lists.
All supply systems with DataTrak and 24 VDC or 100-240 VAC power supplies are ETL approved.
NOTICE
To prevent damage to DataTrak soft key buttons, do
not press the buttons with sharp objects such as pens,
plastic cards, or fingernails.
Systems with the GD as the first and second digits are Dura-Flo supply sys-
tems.
Some configurations in the following matrix cannot be built. See the Product
Selection Guide for available systems
ti11157a
