Graco REACTOR E-XP2 Operation

AdvancedDisplayModule(ADM)
Soft Soft
Soft
Keys Keys
Keys
Iconsnexttothesoftkeysindicatewhichmode
oractionisassociatedwitheachsoftkey.Soft
keysthatdonothaveaniconnexttothemare
notactivethecurrentscreen.
NOTICE NOTICE
NOTICE
Topreventdamagetothesoftkeybuttons,do
notpressbuttonswithsharpobjectssuchas
pens,plasticcards,orngernails.
Ico- Ico-
Ico-
n n
n
Function Function
Function
StartProportioner
StartandStopProportionerinJogMode
StopProportioner
Turnonoroffthespeciedheatzone
Parkpump
EnterJogMode.SeeJogMode,page49.
ResetCycleCounter
(pressandhold)
SelectRecipe
Search
MoveCursorLeftOneCharacter
Ico- Ico-
Ico-
n n
n
Function Function
Function
MoveCursorRightOneCharacter
Togglebetweenupper-case,lower-case,
andnumbersandspecialcharacters
Backspace
Cancel
Clear
TroubleshootSelectedError
Increasevalue
Decreasevalue
Nextscreen
Previousscreen
Returntorstscreen
Calibrate
Continue
22
333023U
