Graco REACTOR E-XP2 Operation

Setup
Connect Connect
Connect
Power Power
Power
Allelectricalwiringmustbedonebya
qualiedelectricianandcomplywithalllocal
codesandregulations.
1.Turnmainpowerswitch(MP)OFF.
2.Openelectricalenclosuredoor.
NOTE: NOTE:
NOTE:
Terminaljumpersarelocatedinside
theelectricalenclosuredoor.
3.Installsuppliedterminaljumpersinthe
positionsshowninimageforthepower
sourceused.
4.Routepowercablethroughstrainrelief(EC)
inelectricalenclosure.
5.Connectincomingpowerwiresasshown
inimage.Gentlypullonallconnectionsto
verifytheyareproperlysecured.
6.Verifyallitemsareconnectedproperly
asshowninimagethencloseelectrical
enclosuredoor.
NOTE: NOTE:
NOTE:
350–415VACsystemsarenotdesigned
tooperatefrom480VACpowersource.
SeeModelsforReactorpowerrequirements.
333023U 29
