Graco REACTOR E-XP2 Operation

JogMode
Circulation Circulation
Circulation
Through Through
Through
Gun Gun
Gun
Manifold Manifold
Manifold
NOTICE NOTICE
NOTICE
Topreventequipmentdamage,donot
circulateuidcontainingablowingagent
withoutconsultingwithyourmaterialsupplier
regardinguidtemperaturelimits.
NOTE: NOTE:
NOTE:
Optimumheattransferisachievedat
loweruidowrateswithtemperatureset
pointsatdesireddrumtemperature.Low
temperaturerisedeviationerrorsmayresult.
Circulatinguidthroughthegunmanifold
allowsrapidpreheatingofthehose.
1.Installgunuidmanifold(P)onaccessory
circulationkit(CK).Connecthighpressure
circulationlines(R)tocirculationmanifold.
The Fusion AP gun manifold is shown.
CK CK
CK
Gun Gun
Gun
Manual Manual
Manual
246362
FusionAP
309818
256566FusionCS313058
2.Routecirculationlinesbacktorespective
componentAorBsupplydrum.Use
hosesratedatthemaximumworking
pressureofthisequipment.See
TechnicalSpecications,page76.
3.FollowproceduresfromStartup,page45.
4.Turnmainpowerswitchon
.
5.Settemperaturetargets.See
Targets,page40.
6.Press
tocirculateuidinjogmodeuntil
AandBtemperaturesreachtargets.See
JogMode,page49formoreinformation
aboutjogmode.
Jog Jog
Jog
Mode Mode
Mode
Jogmodehastwopurposes:
•Itcanspeeduidheatingduringcirculation.
•Itcaneasesystemushingandpriming.
1.Turnmainpowerswitchon
.
2.Presscirculate
toenterjogmode.
3.Pressupordown
tochangejogspeed
(J1throughJ20).
NOTE: NOTE:
NOTE:
Jogspeedscorrelateto3-30%of
motorpower,butwillnotoperateover700
psi(4.9MPa,49bar)foreitherAorB.
4.Press
tostartmotor.
5.Tostopthemotorandexitjogmodepress
or.
333023U 49
