HoseFTSmustbeconnectedinallmodes
toreducetheriskofstaticsparking.Static
sparkingcancausefumestoigniteorexplode.
Groundingprovidesanescapewireforthe
electriccurrent.
IfthesystemproducestheT6DHsensorerror
alarmortheT6DTsensorTCMalarm,useHose
ManualModeuntilthehoseRTDcableorFTS
canberepaired,oruseHoseResistanceMode
withaproperlysavedcalibrationfactor.
DonotuseHoseManualModeforextended
periodsoftime.Thesystemperformsbest
whenusedinHoseFTSModeorHoseResistance
Mode.OnlyuseHoseResistanceModewith
genuineGracoheatedhoses.
Hose Hose
Hose
Control Control
Control
Mode Mode
Mode
Description Description
Description
FTS
Theuidtemperaturesensor
(FTS)installedinthehose
automaticallycontrolsthehose
uidtemperature.Thismode
requirestheFTStobeinstalled
andworkingproperly.
Resistance
Thehoseheaterelement
resistanceautomatically
controlsthehoseuid
temperature.Thismode
requiresacalibrationfactor(see
CalibrationProcedure,page56).
ManualThesystemsuppliesasetamount
ofhosecurrent(amps)toheat
thehose.Thehosecurrentisset
bytheuser.Thismodehasno
pre-programmedcontrolandis
designedtobeusedforalimited
amountoftimeuntiltheFTS
issuesarexed,oracalibration
factorisproperlysaved(see
CalibrationProcedure,page56).
