Graco REACTOR E-XP2 Operation

Setup
Connect Connect
Connect
Heated Heated
Heated
Hose Hose
Hose
to to
to
Proportioner Proportioner
Proportioner
NOTICE NOTICE
NOTICE
Toavoiddamagetothehose,onlyconnect
Reactor2proportionerstogenuineGraco
heatedhoses.
Refertoyourheatedhosemanualfordetailed
connectioninstructions.
1.Turnoffmainpowerswitch(MP).
2.Forproportionerswithterminationbox(TB):
a.Connecthosepowerwirestoterminal
block(T)onterminationbox(TB).
Removeboxcoverandloosenlower
strainrelief(E).Routehosewires(V)
throughtheboxstrainreliefandfully
insertintoterminalblock(T).AandB
hosewirepositionsarenotimportant.
Torqueto35–50in-lb(4.0–5.6N·m).
b.Fullytightenstrainreliefscrewsand
replacecover.
Figure11TerminationBox
3.Forproportionerswithelectricalsplice
connectors(S):
a.Connecthosepowerwirestoelectrical
spliceconnectors(S)fromproportioner.
Wrapconnectionswithelectricaltape.
Figure12ElectricalSpliceConnectors
4.ConnectFTScableconnectors(R).Fully
tightenRTDconnectors,ifprovided.
333023U 31
