Graco REACTOR E-XP2 Operation

Spraying
Enable Enable
Enable
Hose Hose
Hose
Resistance Resistance
Resistance
Mode Mode
Mode
Thismoderequiresacalibrationfactortorun
(seeCalibrationProcedure,page56).
1.EnterSetupModeandnavigatetoSystem
screen3.
2.SelectResistancefromthedrop-downmenu.
NOTE: NOTE:
NOTE:
Ifnocalibrationfactorisshown,
followtheCalibrationProcedure,page56.
NOTICE NOTICE
NOTICE
Topreventdamagetotheheatedhose,a
hosecalibrationisrequiredifanyofthe
followingconditionsaretrue:
•Thehosehasneverbeencalibrated
before.
•Asectionofhosehasbeenreplaced.
•Asectionofhosehasbeenadded.
•Asectionofhosehasbeenremoved.
3.EnterRunModeandnavigatetotheTargets
screen.Usetheupanddownarrowstoset
thedesiredtemperature.
NOTE: NOTE:
NOTE:
HoseResistanceModecontrolsthe
averageuidtemperatureoftheAandB
uid.Setthehosetemperaturesetpoint
halfwaybetweentheAandBtemperature
setpointsandadjustasneededtoachieve
desiredperformance.
4.NavigatebacktotheRunModehomescreen.
TheHoseResistanceModeiconwilldisplay.
NOTE: NOTE:
NOTE:
WhenHoseResistanceModeis
enabledandthehoseheatisoff,thehose
temperaturewilldisplay“---”.InHose
ResistanceMode,temperaturevaluesare
onlydisplayedwhentheheatison.
333023U 53
