Graco REACTOR E-XP2 Operation

AdvancedDisplayModule(ADM)Operation
Diagnostic Diagnostic
Diagnostic
Screen Screen
Screen
Usethisscreentoviewinformationforall
systemcomponents.
Thefollowinginformationisdisplayed:
Temperature Temperature
Temperature
•AChemical
•BChemical
•HoseChemical
•TCMPCB—temperaturecontrolmodule
temperature
Amps Amps
Amps
•ACurrentH(0–25Afor10kWheater,0–38A
for15kWheater)
•BCurrentH(0–25Afor10kWheater,0–38A
for15kWheater)
•HoseCurrentH(0–45Atypical)
Volts Volts
Volts
•MCMBusH—displaysthevoltagesuppliedto
themotorcontroller,whichistheDCvoltage
thathasbeenconvertedfromtheACvoltage
suppliedtothesystem(275–400Vtypicalfull
range)
•AVoltage–VoltagesuppliedtoAheater
(195–240Vtypical)
•BVoltage–VoltagesuppliedtoBheater
(195–240Vtypical)
•HoseVoltage(90V)
Pressure Pressure
Pressure
•PressureA—chemical
•PressureB—chemical
Cycles Cycles
Cycles
•CPM—cyclesperminute
•TotalCycles—lifetimecycles
NOTE: NOTE:
NOTE:
HMaximumvaluesbasedonmaximum
inputvoltage.Valueswilllowerwithlowerinput
voltage.
Job Job
Job
Data Data
Data
Screen Screen
Screen
Usethisscreentoenterajobnameornumber.
Recipes Recipes
Recipes
Screen Screen
Screen
Usethisscreentoselectanenabledrecipe.Use
theupanddownarrowstohighlightarecipe
andpress
toload.Thecurrentlyloaded
recipeisoutlinedbyagreenbox.
NOTE: NOTE:
NOTE:
Thisscreenwillnotdisplayifthereare
notanyenabledrecipes.Toenableordisable
recipes,seeRecipesSetupScreen,page37.
333023U 43
