Graco REACTOR E-XP2 Operation

Startup
11.PresstoactivateADM.
12.Ifnecessary,setuptheADMinSetup
Mode.SeeAdvancedDisplayModule(ADM)
Operation,page32.
13.Preheatthesystem:
a.Press
toturnonhoseheatzone.
NOTE: NOTE:
NOTE:
Inordertorunwithoutauid
temperaturesensorinHoseResistance
Mode,acalibrationfactormustbesaved.
SeeCalibrationProcedure,page56.
Thisequipmentisusedwithheated
uidwhichcancauseequipment
surfacestobecomeveryhot.Toavoid
severeburns:
•Donottouchhotuidorequipment.
•Donotturnonhoseheatwithout
uidinhoses.
•Allowequipmenttocoolcompletely
beforetouchingit.
•Wearglovesifuidtemperature
exceeds110°F(43°C).
Thermalexpansioncancause
overpressurization,resultingin
equipmentruptureandseriousinjury,
includinguidinjection.Donot
pressurizesystemwhenpreheating
hose.
b.Ifyouneedtocirculateuidthroughthe
systemtopreheatthedrumsupply,see
CirculationThroughReactor,page48.If
youneedtocirculatematerialthrough
theheathosetothegunmanifold,see
CirculationThroughGunManifold,page
49.
c.Waitforthehosetoreachsetpoint
temperature.
NOTE: NOTE:
NOTE:
Hoseheat-uptimemayincrease
atvoltageslessthan230VACwhen
maximumhoselengthisused.
d.Press
toturnonAandBheatzones.
333023U
47
