Graco REACTOR E-XP2

PerformanceCharts
Heater Heater
Heater
Performance Performance
Performance
Chart Chart
Chart
140
(60.0)
130
(54.4)
120
(48.9)
110
(43.3)
100
(37.8)
90
(32.2)
80
(26.6)
70
(21.1)
60
(15.5)
50
(10.0)
40
(4.4)
30
(-1.1)
20
(-6.6)
10
(-12.2)
0 0.5
(1.9)
1.0
(3.8)
1.5
(5.7)
2.0
(7.6)
2.5
(9.5)
3.0
(11.4)
3.5
(13.2)
4.0
(15.1)
4.5
(17.0)
L
K
ti28705a
DeltaTin
degreesF
(degreesC)
FlowRateingpm(lpm)
* Heater performance data is based on testing with 10 wt.
hydraulic oil and 230V across heater power wires.
KEY: KEY:
KEY:
K=10.2kW
L=15.3kW
333023U 75
