Graco SDX Series User Manual

Contents
3A8626C 3
Models
SDX Series
(Part List page 31)
*Each SDX Model hose reel shown in the table is available in several colors. The last character of each Model No.
indicates the hose reel color. For example: A = white, B = metallic blue, C = red, D = black, F = yellow.
The SDX Series Models table uses the generic # symbol to represent the last character. For example, to order a
white SDL56# model reel hose, the # symbol is replaced with “A” - SDL56A would be the complete model number
used.
Model No.* Size Type
Maximum Working
Pressure psi
(MPa, bar)
Media
Connection Size
Line Size
(in.)
Length
(ft)
Inlet Outlet
SDL2D# 10 Bare 300 (2.1, 21) Air/Water 1/2 npsm(m) 3/8 npsm(f) 3/8 50
SDL6D# 20 Bare 300 (2.1, 21) Air/Water 1/2 npsm(m) 1/2 npsm(f) 1/2 50
SDL23# 10 Hose 300 (2.1, 21) Air/Water 1/2 npsm(m) 3/8 npt(m) 3/8 35
SDL25# 10 Hose 300 (2.1, 21) Air/Water 1/2 npsm(m) 3/8 npt(m) 3/8 50
SDL56# 20 Hose 300 (2.1, 21) Air/Water 1/2 npsm(m) 3/8 npt(m) 3/8 65
SDL5J# 20 Hose 300 (2.1, 21) Air/Water 1/2 npsm(m) 3/8 npt(m) 3/8 65
SDL33# 10 Hose 300 (2.1, 21) Air/Water 1/2 npsm(m) 1/2 npt(m) 1/2 35
SDL65# 20 Hose 300 (2.1, 21) Air/Water 1/2 npsm(m) 1/2 npt(m) 1/2 50
SDL6H# 20 Hose 300 (2.1, 21) Air/Water 1/2 npsm(m) 1/2 npt(m) 1/2 50
SDM3B# 10 Bare 2000 (14, 138) Oil 1/2 npsm(m) 1/2 npsm(f) 1/2 35
SDM6D# 20 Bare 2000 (14, 138) Oil 1/2 npsm(m) 1/2 npsm(f) 1/2 50
SDM33# 10 Hose 2000 (14, 138) Oil 1/2 npsm(m) 1/2 npt(m) 1/2 35
SDM65# 20 Hose 2000 (14, 138) Oil 1/2 npsm(m) 1/2 npt(m) 1/2 50
SDM6H# 20 Hose 2000 (14, 138) Oil 1/2 npsm(m) 1/2 npt(m) 1/2 50
