Dimensions
44 3A8626C
XNX Models
*Measurement taken from center to center of bolt slot/holes.
Pressure Size A B* C D E G
Low 20
6.5 in.
(165 mm)
7.5 in.
(191 mm)
7.7 in.
(196 mm)
9.0 in.
(229 mm)
18.2 in.
(462 mm)
20.0 in.
(508 mm)
Medium 20
High 20
