Installation
14 3A8626C
Ceiling Installations
XDX Models Only
1. Reposition the guide arm to position AA. See Step
2, page 13.
2. Position the hose reel so the pedestal is facing
upward.
3. Using the man-lift, raise the reel as close to the
mounting location as possible.
4. Bolt the hose reel to the mounting, making sure that
it is secure before lowering the man-lift.
5. Connect the inlet supply line to the inlet hose of the
reel. See Hose Installation, page 18.
NOTE: None of the hose reels listed in this manual
come with a Hose Inlet Kit.
6. Flush the hose following the instructions in Flush
the Equipment, page 9.
7. Re-position the hose stop, if needed, so that the
hose extends far enough for all operators to reach
the dispense valve, then tighten the nuts to
securely hold the hose stop in place.
8. Install the motor or dispense valve to the end of the
hose following the instructions provided with the
dispense equipment.
NOTE: if an enclosure is being installed around the
hose reel, first install the dispense valve or motor to the
hose end.
9. See Adjust Spring Tension, page 20.
To reduce the risk of injury, always use a man-lift
while doing a hose reel ceiling installation.
