Repair
3A8626C 25
9. Detach the spool assembly (5).
NOTE: Check that the washer (5j) is not adhering to the
inside of the pedestal assembly (16). Discard the
washer (5j) with the old spool. A new washer (5j) is
installed on the new spool (5) and is part of the new
spool (5) assembly.
10. Install the new spool assembly (5).
11. Reinstall the guide arm (18) and pedestal assembly
(16) over the spool (5) and install the nut (5g) and
tighten (torque 85 - 105 ft-lb/115.2 - 142.4 N•m).
12. Ensure that the o-ring (6b) is not damaged, then
replace the swivel assembly (6) (torque 25 - 30
ft-lb/33.9 -40.7 N•m).
13. Slide the hose reel onto the base plate (104) and
install the hold-down plate (101), the washer (103),
and the cap screw (102). Firmly tighten the screw
(102).
14. Install the hose onto the spool following the Hose
Installation instructions, page 18.
15. Flush the hose following the Flush the Equipment
instructions, page 9.
16. Set the spring tension following the Adjust Spring
Tension instructions, page 20.
Replace Spool - Dual Pedestal
XDX or XNX Models
A complete list of replacement Kits is available on
page 38. Use all of the new parts included in the kit.
When replacing the spool assembly, it is
recommended that a Swivel Replacement Kit be
ordered. To determine the correct swivel
replacement for your reel, see page 38.
1. Follow the Pressure Relief Procedure, page 9.
2. Completely remove all spring tension. See
Decrease Spring Tension information, page 21.
3. Remove the reel from service.
4. Completely remove the hose from the spool and set
it aside for re-installation on the new spool.
5. Remove the large nut (11) (F
IG. 21).
6. Remove the two screws (27) holding the pedestal
(26) to the base (24) and the two screws (27)
holding the guide arm (29) to the guide arm (30)
(F
IG. 21).
NOTE: XNX models do not have a guide arm.
7. Completely remove, as one piece, the guide arm
(29) and pedestal assembly (26) and set it aside for
re-installation on the new spool (F
IG. 21).
NOTE: These parts do not have to be disassembled.
