Graco SDX Series User Manual

Kits
40 3A8626C
Label, Fluid Identification: 24A223
.
Latch Kit: 15Y503
(Instruction Manual: 406801)
Enclosure Retrofit Kit: 24C100
(Instruction Manual: 313902)
FIG. 28
Description Qty
SCREW, M8 x 1.25 X 20 2
PAWL, ratchet 1
SPRING, ratchet, pawl 1
SCREW, M10 x 1.50 x 25 1
BUSHING 1
NUT, M8 x 1.25 4
SCREW, M8 x 1.50 x 40 1
NUT, M10 x 1.50 1
Description Qty
ARM, hose guide 1
BASE, reel, enclosed 1
NUT, lock 4
SCREW 4
WASHER, flat 3
BOLT, M10 x 40 lg 1
NUT, hex 1
WASHER, lock, spring 1
NUT, lock 4
SCREW 4
NUT, hex 5
WASHER, lock 1
SCREW, shoulder, #10 1
