Technical Specifications
3A8626C 51
Technical Specifications
SDX, XDX and XNX 10/20 Series Hose Reels
US Metric
Low Pressure Hose Reels
Maximum fluid working pressure (Air/Water, all
hose diameters)
300 psi 2.1 MPa, 21 bar
Inlet size 1/2 npsm male
Swivel outlet size 3/8 or 1/2 npsm(f)
Hose outlet size 3/8 or 1/2 npt(m)
Operating temperature range -20° – 190°F -29° – 88°C
Wetted parts - Bare Hose Reel only Stainless steel, anodized aluminum, Nitrile rubber
Medium Pressure Hose Reels
Maximum fluid working pressure (Oil) 2000 psi 14 MPa, 138 bar
Inlet size 1/2 npsm male
Swivel outlet size 1/2 npsm (f)
Hose outlet size 1/2 npt male
Operating temperature range -20° – 190°F -29° – 88°C
Wetted parts - Bare Hose Reel only Zinc plated steel, anodized aluminum, Nitrile rubber
High Pressure Hose Reels
Maximum fluid working pressure (grease, all hose
diameters)
5000 psi 35 MPa, 345 bar
Inlet size 3/8 npsm male
Swivel outlet size
3/8 npsm (f)
Hose outlet size 1/4 npt male
Operating temperature range -40° – 200°F -40° – 93°C
Wetted parts - Bare Hose Reel only Zinc plated steel, Nitrile rubber, steel
Dry Weight (Approximate)*
SDX Models (for example SDH55B) 52 lbs (23.6 kg)
XDX Models (for example XDH55B) 59 lbs (26.7 kg)
XNX Models (for example XNL56D) 52 lbs (23.6 kg)
Noise (dBa)
Maximum sound pressure
SDX Model 80 dB(A)
XDX and XNX Model 78 dB(A)
Maximum sound power
SDX Model 87 dB(A)
XDX and XNX Model 88 dB(A)
All readings taken at assumed retraction rate, from assumed operator position.
Sound power measured per ISO-9614-2.
Notes
* Weight will vary with each swivel base and hose selection.
All trademarks or registered trademarks are the property of their respective owners.
