Graco SDX Series User Manual

Parts
3A8626C 37
Parts XNX Series
*Included in Swivel Kit, page 38.
‡Included in Spool Kit, page 38.
▲Replacement safety labels, tags, and cards are available at no cost.
A complete list of all available kits begins on page 38.
Ref Part No Description Qty
2 WASHER, flat 1
5 KIT, spool (see page 38) (includes
parts 5e-5k)
1
5e‡ RING, retaining
1
5h‡ SPOOL
1
5j‡ WASHER, 30 mm
1
5k‡ WASHER, square center
1
6 133506 KIT, swivel, XDX grease 3/8 1
133507 KIT, swivel, XDX oil 1/2 1
133508 KIT, swivel, XDX A/W 1/2 1
133509 KIT, swivel, XDX A/W 3/8 1
*6a 155470 FITTING, swivel, 90° (XNL65D and
XNM65D)
*6a 15Y397 FITTING, swivel, 90° (XNH55D)
*6a 161037 FITTING, swivel, 90° (XNL56D)
1
*6c SHAFT, swivel
1
11 186579 NUT, hex, 3/8 in. - 18 npsm (XNH55D)
1
11 186580 NUT, hex, 1/2 in. - 14 npsm (Models
XNL56D, XNL65D, AND XNM65D)
1
14 ADJUSTER, power spring
1
17 100023 WASHER, 8 mm
1
18 SCREW, M8 x 1.25 x 120
1
19 SCREW, M5 x .80 x 20
2
24 BASE, dual
1
26 PEDESTAL
1
27‡ SCREW, M8 x 1.25 x 20
2
28 124461 HOSE, 50 ft. (Model XNH55D)
1
25U037 HOSE, 65 ft. (Model XNL56D)
1
25U039 HOSE, 50 ft. (Model XNL65D)
1
26C122 HOSE, coupled, 50 ft. (Model
XNM65D)
1
34▲ 15W036 LABEL, warning
1
37 BUSHING, pawl
1
38 PAWL, ratchet
1
39 BOLT, M10 x 1.5 x 25 lg
1
40 SPRING, ratchet pawl
1
48 KIT, stop, hose (page 41)
1
