Graco SDX Series User Manual

Parts
3A8626C 31
Parts SDX Series
Ref Part No. Description Qty
5
KIT, spool (includes 5a-5j) (see page
38)
1
5a‡
WASHER, thrust (all SDL and SDM
models)
1
5a‡ WASHER, thrust (all SDH models) 1
5f‡ 186579
NUT, hex, 3/8 in. x 18 npsm (SDH
Models)
1
5f‡ 186580
NUT, hex, 12 in. - 14 npsm (SDL and
SDM Models)
1
5g‡ SPOOL 1
5j‡ RING, snap 1
6 133502
KIT, swivel, SDX A/W 3/8, Models
SDL23#, SDL25#, SDL2D#, SDL56#,
SDL5J
1
133503
KIT, swivel, SDX A/W 1/2, Models
SDL33#, SDL65# SDL6D#, SDL6H#
1
133504
KIT, swivel, SDX oil 1/2, Models
SDM33#, SDM3B#, SDM65#,
SDM6D#, SDM6H#
1
*6a 155470
FITTING, swivel, 90°, npsm (Models
SDL3B, SDL6D, SDL33, SDL65,
SDM3B, SDM6D, SDM33, SDM65)
1
*6a 161037
FITTING, swivel, 90°, npsm (Models
SDL23, SDL25, SDL56)
1
*6a 15Y397
FITTING, swivel, 90°, npsm (SDH
Models)
2
*6b O-RING 1
*6c SHAFT, swivel 1
13 104541 NUT, lock, M8 x 1.25 4
15 SPRING, ratchet, pawl 1
16 BASE 1
17 BOLT, M10 x 1.50 x 25 1
18 15V139
ARM, guide (Metallic Blue) (Models
SDL23, SDL25, SDL33, SDM33,
SDM3B, SDH15, SDH1D, SDH23)
15V141
ARM, guide (Yellow) (Models SDL23,
SDL25, SDL33, SDM33, SDM3B,
SDH15, SDH1D, SDH23)
15V142
ARM, guide (Red) (Models SDL23,
SDL25, SDL33, SDM33, SDM3B,
SDH15, SDH1D, SDH23)
15V143
ARM, guide (White) (Models SDL23,
SDL25, SDL33, SDM33, SDM3B,
SDH15, SDH1D, SDH23)
15V144
ARM, guide (Black) (Models SDL23,
SDL25, SDL33, SDM33, SDM3B,
SDH15, SDH1D, SDH23)
15V157
ARM, guide (Metallic Blue) (Models
SDL56, SDL65, SDM65, SDM6D,
SDH55, SDH5D)
15V159
ARM, guide (Yellow) (Models SDL56,
SDL65, SDM65, SDM6D, SDH55,
SDH5D)
15V160
ARM, guide (Red) (Models SDL56,
SDL65, SDM65, SDM6D, SDH55,
SDH5D)
15V161
ARM, guide (White) (Models SDL56,
SDL65, SDM65, SDM6D, SDH55,
SDH5D)
15V162
ARM, guide (Black) (Models SDL56,
SDL65, SDM65, SDM6D, SDH55,
SDH5D)
24 BUSHING, pawl 1
25 PAWL, ratchet 1
26 218591
KIT, roller (includes 25a-25d) (see
page 41)
1
26a BRACKET, roller 1
26b PIN, roller 4
26c ROLLER, hose 4
26d SCREW, M6 x 1.0 x 20 4
30 KIT, stop, hose (see page 41) 1
33 109158
HOSE, 50 ft., npt (Models SDH15A,
SDH15B, SDH15C, SDH15D,
SDH15E, SDH15F)
1
124461
HOSE, 50 ft., npt (Models SDH55A,
SDH55B, SDH55C, SDH55D,
SDH55E, SDHE5F)
1
25U035
HOSE, 35 ft., npt (Models SDL23A,
SDL23B, SDL23C, SDL23D,
SDL23E, SDL23F)
1
25U036
HOSE, 50 ft., npt (Models SDL25A,
SDL25B, SDL25C, SDL25D,
SDL25E, SDL25F)
1
25U037
HOSE, 65 ft., npt (Models SDL56A,
SDL56B, SDL56C, SDL56D,
SDL56E, SDL56F)
1
25U038
HOSE, 35 ft., npt (Models SDL33A,
SDL33B, SDL33C, SDL33D,
SDL33E, SDL33F)
1
Ref Part No. Description Qty
