Graco SDX Series User Manual

Kits
3A8626C 41
Hose Inlet Kit
(Instruction Manual 406741)
Mounting Adapter: 22A224
(page 11)
Hose Guide Kits
Roller Bracket Repair: 218591
(Instruction Manual: 406743)
Cabinet Mounting Kit: 15Y478
Hose Reel Stop Kit
(Instruction Manual: 406742)
1/4 in. and 3/8 in. ID Hoses: 218340
3/8 in. and 1/2 in. ID Hoses: 218341
1/4 in. ID Hoses: 222225
Description Qty
1/4 NPT Inlet: 224417
HOSE, coupled, 24 in. 1
FITTING, UNION, ADAPTER, 90° 1
3/8 Inlet: 218550
HOSE, coupled, 24 in. 1
FITTING, union, adapter, 90° 1
1/2 NPT Inlet: 218549
HOSE, coupled, 24 in. 1
FITTING, swivel, union, 90° 1
Description Qty
BASE, adapter 1
SCREWS, 3/8 in. - 16 x 3/4 in. 4
Description Qty
BRACKET, hose guide 1
PIN, roller 4
ROLLER, hose 4
NUT, lock, #10 - 32 4
SCREW, #10 - 32 x 3/4 in. 4
SCREW, M6 x 1.0 x 20 4
Description Qty
BRACKET, hose guide 1
PIN, roller 4
ROLLER, hose 4
PLATE, mounting 1
NUT, lock, #10 - 32 4
SCREW, #10 - 32 x 3/4 in. 4
Description Qty
NUT, hex, jam 2
SCREW, machine, phillips 2
STOP, hose, 0.656 in. ID 2
Description Qty
NUT, hex, jam 2
SCREW, machine, phillips 2
STOP, hose, 0.782in. ID Kit 2
Description Qty
NUT, hex, jam 2
SCREW, machine, phillips 2
STOP, hose, 0.53 in. ID Kit 2
