syncFURNACE OD Instruction & Installation Manual – Rev 09 Pg. 15 of 81
mOD-200-22L
mOD-200-18H
Inch mm Inch mm
A - INTERNAL PRV TO DRAIN 3/4" NPT FEMALE 6.44 163 4.41 112
B - CONDENSATE TO DRAIN 7/8" CORR HOSE 9.63 244 5.13 130
C - COLD WATER [IN] 3/4" NPT FEM ALE 3.50 89 1.04 26
D - HOT WATER [OUT] 3/4" NPT FEM ALE 8.21 209 3.00 76
E - RE-CIRC LINE [IN] 3/4" NPT FEM ALE 5.18 132 3.00 76
F - GAS 1/2" NPT FEMALE 2.18 55 24.20 615
Pipe Connection
Thread
Specification
Location
Xref ↔
Location
Yref ↕
Inch mm Inch mm
Z 1
44.50 1130
Z 11
23.13 588
Z 2
24.00 610
Z 12
0.88 22
Z 3
1.50 38
Z 13
22.13 562
Z 4
1.50 38
Z 14
16.92 430
Z 5
18.00 457
Z 15
9.45 240
Z 6
23.00 584
Z 16
19.66 499
Z 7
37.00 940
Z 17
0.50 13
Z 8
45.18 1148
Z 18
22.93 582
Z 9
47.39 1204
Z 19
0.50 13
Z 10
0.88 22
Z 20
6.60 168
Z 21
20.40 518
Z 22 11.50 292
Dimension #
Length
Dimension #
Length
