GRAPHTEC CE-3000-120 AP - Rear View

1-4
Introduction
Rear View
Power switch
AC power inlet
Alignment shaft
Basket
Stand
AC power inlet......... Connects the power cord to the cutting plotter.
Power switch ........... Turns the power supply to the cutting plotter on or off.
Stand ........................ Supports the cutting-plotter unit.
Alignment shaft....... Used when loading roll media.
Basket ...................... Used to catch media after it has been cut.
