GRAPHTEC CE-3000-120 AP - 1.3 Assembling the Stand

1-6
Introduction
1.3 Assembling the Stand
Stand Construction
The stand is made up of the following parts.
Stand side bar (L/R) Center bar
Alignment shaft
Center bar
Hexagonal socket bolt (M6) x 8
Allen wrench (M6)
Stock shaft
Basket Construction
The basket is made up of the following parts.
Sheet support pipe x 2
Sheet support pipe bracket x 2 Rubber cap x 4 Hexagonal socket bolt (M6) x 4
Sheet
