Appendix A Main Specifications
*1 Depending on the shape of the roll stoppers, the width will be 1140 mm when a 2-inch core is used.
*2 HP-GL
TM
is a registered trademark of Hewlett-Packard Company
*3 When using Graphtec-specified media and cutting conditions.
*4 Includes the stand and basket
Item CE3000-120AP
CPU 32-bit
Configuration Grit-rolling
Drive system Digital servo
Maximum cutting area 1164 x 50 m (when the 3-inch core is used)
Maximum guaranteed cutting area 1164 x 3 m (when the 3-inch core is used)*
1
Compatible media widths 160 to 270, 300 to 400, 440 to 540, 580 to 680, 710 to 810, 850 to
950, 990 to 1090, 1120 to 1220 mm (the effective drawing area is the
maximum obtainable area for the corresponding medium width)
Compatible maximum media width 3-inch core: 1220 mm
2-inch core: 1180 mm
Maximum loadable media length 100 m/roll
Media types Fine quality paper for apparel patterns (64 to 130 g/m
2
)
Roll media diameter: 2-inch, 3-inch
Maximum cutting speed 60 cm/s
Maximum acceleration 13.9 m/s
2
(45° direction)
Specifiable cutting speeds 1 to 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60 cm/s
Cutting force 20 to 300 gf (31 levels)
Mechanical resolution 0.005 mm
Programmable resolution GP-GL: 0.1/0.5/0.025/0.01 mm
HP-GL
TM
*
2
: 0.025 mm
Repeatability precision Within 0.1 mm/2m*
3
No. of pens mountable 2
Compatible cutter blade type Supersteel
Compatible pen type Water-based fiber-tip pens
Interfaces RS-232C/Centronics/USB
Buffer capacity 2 MB
Command modes GL-GP, HP-GL
TM
(control-panel selectable)
Display panel Liquid crystal (16 characters x 1 row)
Rated power supply 100 to 120 VAC, 200 to 240 VAC, 50/60 Hz
Power consumption 100 VA
Operating environment 10 to 35C, 35 to 75% RH
Conditions for guaranteed precision 16 to 32C, 35 to 70% RH
External dimensions (W x D x H) Approx. 1487 x 1020 x 1189 mm*
4
Weight 43 kg*
4
