Press “Back” to the waveform display interface if the current USB flash disc has no
setup files.
■ The save/recall waveform acquisition step is the same as the save/recall setup.
The oscilloscope enters “STOP” state after the saved waveform is recalled and
displayed.
■ Image save
As shown in figure 2-61, waveform images can be saved in the USB flash disc but
cannot be recalled by the oscilloscope. The images are in standard BMP format and
can only be opened by related software in computer.
The images are saved in the root directory of the USB flash disc, and the file name is
defaulted as ASxxxx.BMP, such as GAS0001. BMP.
Table 2-41 Image save function menu:
Option Setup Description
Type Image save Save screen image
Print button Save image
Set the [PRINT] shortcut key as save function;
press the [PRINT] key to save the screen image
in the USB flash disc.
Save Save the screen image in the USB flash disc.
Save difference of two kinds of images:
[PRINT] print button: It is a shortcut key and can immediately save the screen image in
any menu. See the screen capture in application example 3-7.
“Save”: It can be used for saving the screen image in a special menu (see the menu bar
shown in figure 2-61).
