Target group
The product is not a toy. It is not suitable for children under the
age of 14. The transmitter may only be operated by experienced
modelers. If you don‘t have sufficient knowledge about handling
radio-controlled models, contact an experienced modeler or a
model club.
Package content
• Radio control transmitter 33040 Graupner mc-32ex HoTT
• USB-cable
• USB-Adapter for receiver and sensor updates
• 1S3P LiHV transmitter battery with 9000 mAh
• Transmitter strap
• Aluminum case
• Radio control transmitter manual
Note
Graupner is constantly working on the further development
of all products. We therefore reserve the right to change the
scope of delivery in terms of form, technology and equipment.
Technical Data
Radio Control transmitter Graupner mc-32ex HoTT
Frequency band 2.4 … 2.4835 GHz
Modulation FHSS
Transmitting power 100 mW EIRP
Control functions 32 functions of which 8 can be trimmed
64 switch functions
Temperature range -10 … +55 °C
Antenna 1 linear and 1 circula polarized, with
adjustable angle, integrated antenna
Operating voltage 3.6 … 4.35 V
Current consump-
tion
500 ... 1200 mA
Dimensions Approx. 275 x 260 x 115 mm without
hand rests
Weight Approx. 1700 g with battery
Note
The technical data of optional receivers can be found in related
receiver system manual.
WLAN
Frequency band 2.4 … 2.4835 GHz
Modulation
IEEE 802.11b:
DSSS (CCK, DQPSK, DBSK)
IEEE 802.11g: OFDM (64QAM, 16QAM,
QPSK, BPSK);
IEEE 802.11n
HT20: OFDM (64QAM,
16QAM, QPSK, BPSK)
Channels 11
Antenna Omni with 3.0 dBi gain
Bluetooth® 3.0+EDR
Frequency band 2.4 … 2.4835 GHz
Modulation GFSK, Pi/4 DQPSK, 8DPSK
Channels 79
Antenna Chip anteanna with 0 dBi gain
