Grizzly G0452 User Manual

-54-
Model G0452/P/Z (Mfg. Since 08/12)
G0452 Table
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0452001 GIB 50A P0452050A TABLE ASSY W/BASE
1 P0452Z001 DRIVER BIT TORX T20 54 P0452054 CAP SCREW M8-1.25 X 15
2 P0452002 KNIVES 6 X 5/8 X 1/8 3-PC SET 55 P0452055 LOCK WASHER 8MM
2V2 P0452Z002V2 INDEXABLE CARBDE INSERT 10PK 56 P0452056 PIVOT ARM BRACKET
3 P0452003 GIB SCREW 57 P0452057 CAPTIVE PIN
3 P0452Z003 INSERT SCREW TORX T20 M6-1 X 15 58 P0452058 EXT RETAINING RING 5MM
4 P0452004 CUTTERHEAD PULLEY 59 P0452059 LEVER HUB
5 P0452005 RIGHT PILLOW BLOCK 60 P0452060 PIVOT LINK
6 P0452006 BALL BEARING 6203-2RS 61 P0452061 PIVOT LINK STEP BOLT
7 P0452007 KEY 5 X 5 X 30 62 P0452062 SET SCREW M8-1.25 X 8
8 P0452008 SET SCREW M5-.8 X 12 63 P0452063 HEX NUT M12-1.75
9 P0452009 CUTTERHEAD NUT 64 P0452064 INFEED PIVOT SHAFT
9 P0452Z009 L-WRENCH TORX T20 65 P0452065 E-CLIP 12MM
10 P0452010 SET SCREW M6-1 X 10 66 P0452066 LEVER ROD
11 P0452011 CUTTERHEAD 6" 3-KNIFE 67 P0452067 HANDLE
11V2 P0452Z011V2 SPIRALCUTTERHEAD 6" V2.04.15 68 P0452068 DUST CHUTE
12 P0452012 BALL BEARING 6202-2RS 69 P0452069 SEAL
13 P0452013 LEFT PILLOW BLOCK 70 P0452070 CLAMP PLATE
14 P0452014 STUD-DE M10-1.5 X 100, 24 71 P0452071 HEX NUT M8-1.25
15 P0452015 LOCK WASHER 10MM 72 P0452072 SET SCREW M8-1.25 X 25
16 P0452016 HEX NUT M10-1.5 73 P0452073 CAP SCREW M8-1.25 X 16
17 P0452017 BUTTON HD CAP SCR M6-1 X 12 74 P0452074 LOCK LEVER
18 P0452018 FLAT WASHER 6MM 75 P0452075 SWITCH MOUNTING BRACKET V1.03.05
19 P0452019 HANDLE 75A P0452075A CONTROL PEDESTAL ASSY V2.07.07
21 P0452021 HANDWHEEL 75A-1 P0452075A-1 PEDESTAL ARM V2.07.07
22 P0452022 SET SCREW M6-1 X 6 75A-2 P0452075A-2 SWITCH BOX V2.07.07
23 P0452023 LOCK COLLAR 75A-3 P0452075A-3 STRAIN RELIEF 13.5MM V2.07.07
24 P0452024 FLAT WASHER 12MM 75A-4 P0452075A-4 FLANGE BOLT M6-1 X 16
25 P0452025 FLAT WASHER 12MM 75A-5 P0452075A-5 POWER CORD 14G 3W 72" 5-15P
26 P0452026 LEADSCREW 75A-6 P0452075A-6 SWITCH CORD
27 P0452027 LEADSCREW BRACKET 75A-7 P0452075A-7 MOTOR CORD
28 P0452028 LOCK WASHER 8MM 76 P0452076 STRAIN RELIEF V1.03.05
29 P0452029 CAP SCREW M8-1.25 X 50 76A P0452076A STRAIN RELIEF V2.07.07
30 P0452030 PUSH BLOCK 77 P0452077 BUTTON HD CAP SCR M5-.8 X 12
31 P0452031 LOCK HANDLE 78 P0452078 CAP SCREW M10-1.5 X 25
32 P0452032 HEX NUT M6-1 78A P0452078A CAP SCREW M8-1.25 X 25
33 P0452033 SET SCREW M6-1 X 25 79 P0452079 LOCK WASHER 10MM
34 P0452034 TABLE GIB 79A P0452079A LOCK WASHER 8MM
35 P0452035 CUTTERHEAD GUARD LABEL 80 P0452080 FLAT WASHER 10MM
36 P0452036 CUTTERHEAD GUARD 80A P0452080A FLAT WASHER 8MM
37 P0452037 POST W/SLOT 81 P0452081 HEX WRENCH 8MM
38 P0452038 SET SCREW M3-.5 X 10 82 P0452082 HEX WRENCH 6MM
39 P0452039 SPACER 83 P0452083 HEX WRENCH 4MM
40 P0452040 INFEED TABLE STOP 84 P0452084 HEX WRENCH 3MM
41 P0452041 POINTER 85 P0452085 HEX WRENCH 2.5MM
42 P0452042 FLAT WASHER 4MM 86 P0452086 WRENCH 8 X 10MM OPEN-END
43 P0452043 BUTTON HD CAP SCR M4-.7 X 16 87 P0452087 WRENCH 12 X 14MM OPEN-END
44 P0452044 ROLL PIN 4 X 20 229A P0452229A SWITCH PLATE V2.07.07
45 P0452045 END PLATE 230A P0452230A START/STOP SWITCH KEDU HY56 V2.07.07
46 P0452046 TORSION SPRING 262 P0452262 KNIFE SETTING JIG ASSEMBLY
47 P0452047 SPRING HOUSING 262-1 P0452262-1 KNIFE JIG ROD
48 P0452048 RETAINER 262-1 P0452262-1 KNIFE JIG ROD
49 P0452049 BUTTON HD CAP SCR M4-.7 X 16 262-3 P0452262-3 E-CLIP 9MM
