Grizzly G0452 User Manual

Model G0452/P/Z (Mfg. Since 08/12)
-57-
G0452 Base
REF PART # DESCRIPTION REF PART # DESCRIPTION
201A P0452201A WHITE CABINET V2.08.07 224-7 P0452224-7 BALL BEARING 6204ZZ
202 P0452202 HEX NUT M8-1.25 224-8 P0452224-8 CENTRIFUGAL SWITCH 20MM-3450
203 P0452203 FLAT WASHER 8MM 224-9 P0452224-9 CONTACT PLATE 20MM
204 P0452204 UNIVERSAL WHEEL 78MM DIA 225 P0452225 KEY 5 X 5 X 30
205 P0452205 SLEEVE 226 P0452226 V-BELT A38
206 P0452206 CAP SCREW M5-.8 X 10 227 P0452227 MOTOR PULLEY
207 P0452207 STRAIN RELIEF 228 P0452228 SET SCREW M6-1 X 6
208 P0452208 HEX NUT 3/8-16
234
P0452234 EXT RETAINING RING 9MM
209 P0452209 RUBBER FOOT
235
P0452235 FLAT WASHER 12MM
210 P0452210 HEX NUT 5/16-18
236
P0452236 SHAFT 12MM
211 P0452211 FLAT WASHER 10MM
237
P0452237 HEX BOLT M8-1.25 X 50
212 P0452212 MOTOR MOUNT BRACKET
238
P0452238 FLAT WASHER 8MM
213 P0452213 DUST CHUTE
239
P0452239 HEX NUT M10-1.5
214 P0452214 FLAT WASHER 3MM
240
P0452240 FLAT WASHER 10MM
215 P0452215 BUTTON HD CAP SCR M5-.8 X 16
241
P0452241 HEX NUT M8-1.25
216 P0452216 BUTTON HD CAP SCR M5-.8 X 16
242
P0452242 LOCK NUT M12-1.75
217 P0452217 FLAT WASHER 5MM
243
P0452243 FLAT WASHER 8MM
218 P0452218 CABINET REAR COVER
244
P0452244 HEX BOLT M8-1.25 X 100
219 P0452219 HEX BOLT 5/16-18 X 3/4
245
P0452245 TROLLEY WHEEL BOLT
220 P0452220 HEX NUT 5/16-18
246
P0452246 TROLLEY WHEEL
221 P0452221 CARRIAGE BOLT 5/16-18 X 1
247
P0452247 BALL BEARING 6202-2RS
222 P0452222 LOCK WASHER 10MM
248
P0452248 INT RETAINING RING 35MM
223 P0452223 CAP SCREW M10-1.5 X 20
249
P0452249 TROLLEY WHEEL SLEEVE
224 P0452224 MOTOR 1HP 120V 1-PH
250
P0452250 TROLLEY UNIVERSAL KIT
224-1 P0452224-1 FAN COVER
251
P0452251 FLAT WASHER 10MM
224-2 P0452224-2 MOTOR FAN
252
P0452252 HEX BOLT M10-1.5 X 55
224-3 P0452224-3 CAPACITOR COVER
253
P0452253 BRACKET
224-4 P0452224-4 S CAPACITOR 200M 125V 1-1/2 X 2-3/4
254
P0452254 PEDAL
224-5 P0452224-5 JUNCTION BOX
254A
P0452254A PEDAL ASSEMBLY
224-6 P0452224-6 BALL BEARING 6204ZZ
