Inventory Item: (Figure 11) Qty
AG. Sliding Table ............................................... 1
AH. Sliding Table Support Legs ........................ 2
AI. Feet M12-1.75 x 75 w/Nuts ......................... 2
Inventory Item: (Figure 10) Qty
AA. Miter Clamp ................................................ 1
AB. Miter Flip Stop ............................................ 1
AC. Miter Handle w/Flat Washer 8mm .............. 1
AD. Miter Gauge Fence ..................................... 1
AE. Miter Gauge Body ...................................... 1
AF. Miter Guide Bar .......................................... 1
Figure 10. Miter gauge items.
AA
AC
AD
AE
AF
Inventory Item: (Figure 12) Qty
AJ. Crosscut Brace Knobs M8-1.25 x 50 ......... 2
—Flat Washers 8mm ................................. 2
—Square Nuts M8-1.25 .............................. 2
AK. Crosscut Fence Knob M8-1.25 ................... 1
—Flat Washer 8mm ................................... 1
—Crosscut Fence T-Stud M8-1.25 x 60 ..... 1
AL. Crosscut Fence Lock Knob M8-1.25 x 25 . . 1
AM. Pivot Stud ................................................... 1
—Special Washer 8 x 20mm ..................... 1
—Square Nut M8-1.25 ................................ 1
AN. Push Handle M12-1.75 x 14 ........................ 1
—Flat Washer 12mm .................................. 1
—Plastic Washer 12mm ............................. 1
—Push Handle T-Nut M12-1.75 .................. 1
Other Hardware (not shown) Qty
Cap Screws M10-1.5 x 25 (Extension Tables) . . 5
Flat Washers 10mm (Extension Tables) ........... 5
Lock Washers 10mm (Extension Tables) ......... 6
Set Screws M8-1.25 x 25 (Extension Tables) ... 6
Hex Nuts M8-1.25 (Extension Tables) .............. 6
Hex Bolts M6-1 x 16 (Fence Scale) .................. 2
Hex Bolt M6-1 x 25 (Fence Scale) .................... 1
Flat Washers 6mm (Fence Scale) ..................... 3
Lock Washers 6mm (Fence Scale) ................... 3
Hex Nuts M6-1 (Fence Scale) ........................... 3
Cap Screws M6-1 x 16 (CT Support Leg) ......... 4
Lock Washers 6mm (CT Support Leg) ............. 4
Flat Washers 6mm (CT Support Leg) ............... 4
Cap Screws M5-.8 x 12 (Switch) ....................... 2
Lock Washers 5mm (Switch) ............................ 2
Cap Screws M10-1.5 x 30 (ST Leg Plates) ...... 4
Lock Washers 10mm (ST Leg Plates) .............. 4
Cap Screw M10-1.5 x 25 (Hose Support) ......... 1
Flat Washers 10mm (Hose Support) ................. 2
Hex Nut M10-1.5 (Hose Support) ...................... 1
Figure 11. Sliding table items.
AG
AH
AI
Figure 12. Miscellaneous knobs and hardware.
AJ
AK
AL
AM
AN
AO
AP
AB
AO. Support Leg T-Slot Plates .......................... 2
AP. Sliding Table T-Studs M12-1.75 x 35 .......... 2
—Flat Washers 12mm ............................... 2
—Lock Washers 12mm .............................. 2
—Hex Nuts M12-1.75 ................................. 2
