-12-
Model G4000 (Mfg. Since 8/09)
Inventory
Inventory: (Figures 34) Qty
A. Faceplate 7
1
2" ............................................ 1
B. 4-Jaw Chuck 7
1
4" ....................................... 1
C. 3-Jaw Chuck 4" .......................................... 1
D. Reverse Jaws for 3-Jaw Chuck ............1 Set
E. C-Type Tool Holder ..................................... 1
F. Dead Center MT#2 ..................................... 1
G. Dead Center MT#3 ..................................... 1
H. Live Center MT#2 ....................................... 1
I. Change Gears:
30T Gears ............................................... 2
36T Gear ................................................. 1
42T Gear ................................................. 1
45T Gear ................................................. 1
80T Gears ............................................... 2
J. Tool Box...................................................... 1
K. Standard & Phillips Screwdrivers ......1 Each
L. Combo Wrenches 8/10, 12/14mm ..... 1 Each
M. Hex Wrenches 1.5, 2, 4, 5, 6mm .......1 Each
N. Oil Bottle ..................................................... 1
O. Belt Tension Lever Knob ............................ 1
P. Chuck Bars ................................................. 2
Q. 3-Jaw Chuck Key ....................................... 1
R. 4-Jaw Chuck Key ....................................... 1
S. Hardware (Not Shown):
Hex Bolts M10-1.5 x 30 ........................... 2
Hex Bolt M8-1.25 x 30 (C-Type Holder) . . 1
Hex Nuts M8-1.25 (C-Type Holder) ......... 1
Pin 8 x 20mm (C-Type Holder) ............... 1
Phillips Head Screws M8-1.25 x 16 ........ 4
Hex Nuts M8-1.25 ................................... 3
High Hex Nut M8-1.25 ............................ 1
Flat Washers 8mm .................................. 9
Compression Spring 10 x 40mm ............ 1
Figure 3. Model G4000 inventory 1.
A
B
C
D
E
G
F
H
I
Figure 4. Model G4000 inventory 2.
J
K
L
N
M
O
P
Q
R
The following is a list of items shipped with your
machine. Before beginning setup, lay these items
out and inventory them.
If any non-proprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
NOTICE
If you cannot find an item on this list, care-
fully check around/inside the machine and
packaging materials. Often, these items get
lost in packaging materials while unpack-
ing or they are pre-installed at the factory.
