Allgemeine Beschreibung
Übersicht
1 Motorgehäuse
2 Kraftsto󰀨tank
3 Anwerfgri󰀨 mit Starterseil
4 Chokehebel
5 Luftlterdeckel
6 Zündkabel
7 Kraftsto󰀨pumpe
und Treibsto󰀨schläuche
8 Gaszug
9 Kabelführung
10 Oberes Schaftrohr
11 Multifunktions-Handgri󰀨
12 Rohrbefestigunsschraube
13 Unteres Schaftrohr
14 Fadenabschneider
15 Schutzabdeckung/Spulen-
kapsel
16 Spulenkapsel
17 Fadenspule
18 Metallschneidblatt
19 Schneidkopfträger
20 Schutzabdeckung/Metall-
schneidblatt
21 Schaltelement
22 Tragöse für Tragegurt
Bild 1
1
2
7
4
5
3
6
8
9
12
11
13
19
18
20
21
14
22
10
15
16
17
