TM057955
Constant flow rate
This control mode requires an external flow sensor.
See the example below.
Example:
• One external flow sensor.
TM057895
Constant flow rate
Controller settings
For recommended controller settings, see the section
on the controller.
Related information
9.16 Controller (Controller settings)
9.5.7
Constant level
The pump maintains a constant level, independently
of the flow rate.
TM057941
Constant level
This control mode requires an external level sensor.
The pump can control the level in a tank in two ways
(see the figure above):
• As an emptying function where the pump draws
the liquid from the tank.
• As a filling function where the pump pumps the
liquid into the tank.
The type of level control function depends on the
setting of the built-in controller.
Example:
• One external level sensor with emptying function.
TM057896
• One external level sensor with filling function.
TM057965
Controller settings
For recommended controller settings, see the section
on the controller.
Related information
9.16 Controller (Controller settings)
9.5.8
Constant other value
Use this control mode to control a value which is not
available in the Control mode menu. To measure the
controlled value, connect a sensor to one of the
analog inputs. The controlled value is shown in
percentage of the sensor range.
9.5.9
Constant curve
Use this control mode to control the motor speed.
You can set the desired speed in percentage of the
maximum speed in the range from user-set minimum
speed to user-set maximum speed.
TM057957
53
English (GB)
