Office1 // Description of the device position.
Input number 2, you can view FACPs and repeater panels in network.
Input number 3, you can view definitions to ZCP keys as in Fig. 6-10.
Fig. 6-10
Browse
Sum: 32
NO.01 Silence key
NO.02 Zone 01
NO.03 004 Sounder
Sum: 32 // The total number of keys on the ZCP.
NO.01 Silence key // Define key No. 1 as “Silence” key.
NO.02 Zone 01 // Define key No. 2 as zone 1.
NO.03 004 Sounder // Define key No. 3 as sounder whose start-up address is
004.
6.2.2.5 Browsing history log
△
＝
＝
▽
Pressing LOG, the FACP enters the state of browsing history record. Using
and ,
you can browse every item, the screen is shown in Fig. 6-11.
History Record
NO. 200
! FIRE!
TIME: 10:23 14/08
Zone: Name
121 Optical
Fig. 6-11
NO. 200 // The two hundredth history log
! FIRE! // Fire alarm message
TIME: 10:23 14/08 // Date and time of the event
Zone: Name // Zone number, zone name
121 Optical // Device address and type
6.2.2.6 Browsing fault messages
You can view fault messages by pressing VIEW FAULT when the screen is displaying
non-fault messages. The display varies by the type of fault messages. Please refer to
Section 5.3.
