GW Instek ASR-2000 Series User Manual

ASR-2000 Series User Manual
70
Setting the Output Voltage Limit
Background
Setting the voltage limit allows the output voltage
to be set to any level within the voltage limit range.
Steps
1. Press Shift + V to access the Volt
Limit menu.
+
2.
When it is under AC+DC-INT, DC-INT,
AC+DC-ADD or AC+DC-Sync mode.
Use the scroll wheel to toggle between VPK+
(upper) and VPK- (lower) settings followed by
pressing Enter to get into the parameter.
Proceed to the step 3 for setup.
VPK+
Setting
VPK-
Setting
