Accuracy
*5
±(2 % of
reading
+2 W)
±(2 % of
reading
+3 W)
±(2 % of reading +4
W)
Apparent
(VA)
Resolution
1 VA
Accuracy*
5*6
±(2 % of
reading
+2 VA)
±(2 % of
reading
+3 VA)
±(2 % of reading +4
VA)
Reactive
(VAR)
Resolution
1 VAR
Accuracy
*5*7
±(2 % of
reading
+2 VAR)
±(2 % of
reading
+3 VAR)
±(2 % of reading +4
VAR)
Load power factor
Range
0.000 to 1.000
Resolution
0.001
Load crest factor
Range
0.00 to 50.00
Resolution
0.01
Harmonic voltage
Effective value (rms)
Percent (%)
(AC-INT and 50/60
Hz only)
Range
Up to 100th order of the fundamental wave
Full Scale
200 V / 400 V, 100%
Resolution
0.1 V, 0.1%
Accuracy
*8
Up to 20th ±(0.2 % of reading + 0.5 V / 1 V)
20th to 100th ±
(0.3 % of reading + 0.5 V / 1 V)
Harmonic current
Effective value (rms)
Percent (%)
(AC-INT and 50/60
Hz only)
Range
Up to 100th order of the fundamental wave
Full Scale
20 A / 10
A, 100%
30 A / 15
A, 100%
40 A / 20 A, 100%
Resolution
0.01 A / 0,1 A, 0.1%
Accuracy*3
Up to
20th
±(1 % of
reading+0
.4 A/0.2
A)
20th to
100th
±(1.5 % of
reading+0
.4 A/0.2
A)
Up to
20th
±(1 % of
reading+0
.6 A/0.3
A)
20th to
100th
±(1.5 % of
reading+0
.6 A/0.3
A)
Up to 20th
±(1 % of reading+0.8
A/0.4 A)
20th to 100th
±(1.5 % of
reading+0.8 A/0.4 A)
