GW Instek ASR-3000 Series User Manual

APPENDIX
221
*1
The voltage display is set to RMS in AC/AC+DC mode and AVG in DC mode.
*2
AC mode: For an output voltage of 20 V to 200 V / 40 V to 400 V and 23 °C ±
5 °C. DC mode: For an output voltage of 28.5 V to 285 V / 57 V to 570 V and
23 °C ± 5 °C.
*3
An output current in the range of 5 % to 100 % of the maximum current, and 23
°C ± 5 °C.
*4
An output current in the range of 5 % to 100 % of the maximum peak current
in AC mode, an output current in the range of 5 % to 100 % of the maximum
instantaneous current in DC mode, and 23 °C ± 5 °C. The accuracy of the
peak value is for a waveform of DC or sine wave
*5
For an output voltage of 50 V or greater, an output current in the range of 10 %
to 100 % of the maximum current, DC or an output frequency of 45 Hz to 65
Hz, and 23 °C ± 5 °C.
*6
The apparent and reactive powers are not displayed in the DC mode.
*7
The reactive power is for the load with the power factor 0.5 or lower.
*8
An output voltage in the range of 20 V to 200 V / 40 V to 400 V and 23 °C ± 5
°C.
Model
ASR-3000
Others
Protections
UVP, OCP, OTP, OPP, Fan Fail
Display
TFT-LCD, 4.3 inch
Memory Function
Store and recall settings, Basic settings: 10 (0~9
numeric keys)
Arbitrary
Wave
Number of
memories
16 (nonvolatile)
Waveform
length
4096 words
Note
 Product specifications are subject to change
without notice.
 The spec aforementioned applies to when slew
rate mode is the Time mode.
