Both the VPK+ and VPK- Limit values defined by user
will be generally applied to AC+DC-INT, DC-INT,
AC+DC-ADD and AC+DC-Sync modes under the same
voltage range, which divides into 2 levels, high range
including AUTO and 200V and low range covering
100V.
Voltage limit setting is Not available for both
AC+DC-EXT and AC-EXT output modes.
There 6 sets of voltage limits in total.
The minimum voltage limit has relative
connection with the voltage setting. That is, the
voltage setting is never beyond the voltage limit.
The range of voltage limit will be limited within
the certain minimum value in accordance with the
output voltage setting.
