GW Instek GDS-1102B - Page 13

INTERFACE OVERVIEW
13
8. Enter the GDS-1000B’s IP address and socket
port number.
9. Click Validate.
10. A popup will appear to tell you if a VISA socket
session was successfully created.
11. Click Next.
10
11
8
9
12. Choose an alias for the socket connection if you
like.
13. Click Finish to finish the configuration.
12
13
14. The GDS-1000B will now appear under
Network Devices in the Configuration Panel.
