REMOTE CONTROL
163
Description
OUTOFF|OUTON|>V|<V|=V|>C|<C|=C|>P|<
P|=P|AUTO
When OUTOFF, OUTON or AUTO is selected,
parameter <value> will be omitted.
Input trigger: disable output(OUTOFF) and enable
output (OUTON), both of which indicate to disable
or enable respectively the trigger when the
specified controlled channel output.
Voltage trigger: greater than voltage >V, less
than voltage <V, equal to voltage =V, all
of which indicate that when the output voltage of
the specified controlled channel meets the set
trigger condition, it will trigger then.
Current trigger: greater than current >C, less
than current <C, equal to current =C, all
of which indicate that when the output current of
the specified controlled channel meets the set
trigger condition, it will trigger then.
Power trigger: greater than power >P, less
than power <P, equal to power =P, all of
which indicate that when the output power of the
specified controlled channel meets the set trigger
condition, it will trigger then.
Automatic trigger: instrument automatically
triggers after enabling this function.
When either one of the following modes: voltage
trigger >V<V=V, current trigger >C
<C=C, power trigger >P <P=P is
selected, it it required to set parameter <value> (the
specified voltage, current or power value of the
trigger condition).
Example
:TRIGger:OUT:CONDition D0,>V,10
Sets the trigger condition from the trigger output of
D0 data line as output voltage>10V.
