GPP Series User Manual
42
GPP-1326：32V/6A x 1
GPP-2323/3323/4323：
CH1/CH2: 32V/3A x 2
CH3:1.8V/2.5V/3.3V/5V/5A x 1 (GPP-3323)
USB Port Output：3A (GPP-3323)
5V/1A x 1 (GPP-4323)
CH4:15V/1A x 1
1. Press F4 or F5 button for operating the
corresponding Independent to enter the
Independent function. 2. For
setting opertation of parameter, refer to page 37.
The independent button ON/OFF of each
channel is available, while All ON/OFF button
is available for all channels.
Tracking Series and Tracking Parallel Modes
Tracking series operation doubles the Voltage
capacity of the GPP-2323/3323/4323 by internally
connecting CH1 (Master) and CH2 (Slave) in series
and combining the output to a single channel. CH1
(Master) controls the combined Voltage output level.
