OVERVIEW
25
Rear Pane
l
T
erminals
Alternate
input switch
AC
voltage selection:
100V/120
V/220V/230V
±
1
0%, frequency 50/60Hz
AC input
socket and
line fuse
The AC input accep
ts
100V/120
V/220V/230V
AC
. The frequency is
50Hz/60Hz
.
Fuse:
100V/120
V: T6.3A/250V
，
220V/230
V :T3.15A/250
V
，
slow-blow type, S
ee page
195
for details.
USB port
USB device
port for remote
control. See pa
ge
93
for
details.
24
26
