REMOTE CONTROL
95
Connection Usage
This chapter describes how to set and enable port,
as well as all the required preparations prior to
operation.
The GPP series has 2 standard remote control
ports (RS-232, USB), and 2 optional ports (GPIB,
LAN).
It is allowed to control the GPP series by only
single remote control method once time. Before
to use, it’s required to select or confirm
beforehand.
Press the System button followed by pressing
the F1 (Interface) button to select the target
port: F1 (RS-232), F2 (USB), F3 (GPIB), F4
(LAN). The available ports will
appear on the LCD.
The selected port will appear in the status bar
with font color in gray, for instance , whilst
it will change to white color after successful
commnad operation.
To Next Page
