BASIC OPERATION

current displays

in red CC.

OVP/OCP

OVP/OCP displays in white

when OVP is not in activation.

OVP/OCP displays in red and

output is off when OVP is

activated.

OVP/OCP displays in gray when

OVP/OCP functions are off.

Independent Output Mode

Description

Each channel within the models GPP-

1326/2323/3323/4323 series is apart from one

another and capable of operations including

independent setting and individual output, etc.

Connection

+ - + - + - + -

CH3

Load

CH2

Load

CH1

Load

CH4

Load
