GPP Series User Manual
182
Save the current setup to the selected save location.
<NR1> : 0–9, Corresponding to STATE00-STATE09
SAV1
Stores the setting in memory 1(STATE01)
Recall the selected save setting from memory.
<NRf>: 0 - 9 , Corresponding to STATE00-STATE09
*RCL 2
Recalls the setting stored in memory 2(STATE02)
Recall the selected save setting from memory.
<NR1>: 0 – 9 , Corresponding to STATE00-STATE09
RCL2
Recalls the setting stored in memory 2(STATE02)
SCPI Status Registers SCPI
The SCPI instrument configuration is controlled by the status
registers. The Status system records various instrument conditions
into three main register groups: The status byte register, the
standard event register group and the questionable data register
group. The status byte register records a high-level summary of the
other register groups. The following diagram is the SCPI Status
System diagram.
To Next Page
