BASIC OPERATION
43
Tracking series without common terminal
Output
rating
rating 0 - 64V/0 - 3A
Setting
1. Press F4 or F5 button for operating the
corresponding Series to enter the tracking series
function. Yellow SER will be shown on the
status area.
2. Press CH1 button to proceed to CH1/CH2
voltage setting and CH1 limit current setting.
3. Press CH2 button to proceed to CH2 limit
current setting.
4. For setting operation of parameter, refer to
page 37.
Output
The button ON/OFF of CH1/CH2 is
individually available, while All ON/OFF
button is available for all channels.
Load
+ -
