GW Instek GPP-1326 User Manual

BASIC OPERATION
47
Rset
Set rating range of resistance value
under Load mode of active channel
CH1：1Ω-1000Ω
CH2：1Ω-1000Ω
Others
OPP： fixed 50W, non-revisable
OVP/OCP： indentical to Source
Parameter
setting
Vset
Press F4 or F5 button for operating
the corresponding (CV) mode
followed by F1 button (Vset). The
voltage setting area on LCD will be
activated and appears
(red font color with the underline
indicator).
(a) number pad (0-9,.) input; press
unit button F1 (V) or F2 (mV) button
to confirm:
Input 6.54V:
(b) Step input: Press the
left or right arrow
buttons to select high and
low level that require
fine tune (underline
below the corresponding
number value), and scroll
the scroll wheel to
increase or decrease
setting value.
Iset
Press F4 or F5 button for operating
