GW Instek GPP-1326 User Manual

BASIC OPERATION
51
Groups
The number to be executed. It can
NOT exceed 2048 for Start+Groups.
End
Status
There’re 2 statuses after the
necessary Group and Cycle are
executed: output termination or
being hold with the last step.
Parameter
Setting
Cycles
Press the Advance key on control
panel. Select F2 (Sequence) function.
Press F1 (Set) button followed by
selecting F1 (Cycels). The setting on
LCD is activated and appears in red
fond color . Use number
pad to set the parameters directly
and then press the F1 (Done) button
to confirm; or use arrow keys along
with scroll wheel to complete the
setting. Press and hold the F5
(Infinite) button if Infinite execution
is in need.
Start
Under the Sequence function, press
F1 (Set) button followed by selecting
F2 (Start). The setting on LCD is
activated and appears in red fond
color . Use number pad to
set the parameters directly and then
press the F1 (Done) button to
confirm; or use arrow keys along
with scroll wheel to complete the
setting.
Groups
Under the Sequence function, press
F1 (Set) button followed by selecting
F3 (Groups). The setting on LCD is
activated and appears in red fond
color . Use number pad
