BASIC OPERATION
53
Current
Time
Range: 0-33V
Current setting of each group.
Range: 0-3.2A Execution
duration of each group. Range: 1S –
300S
Parameter
Setting
No.
Under the Sequence function, press
F2 (Edit) button followed by
selecting F1 (No.). The setting on
LCD is activated and appears in red
fond color . Use number
pad to set the parameters directly
and then press the F1 (Done) button
to confirm; or use arrow keys along
with scroll wheel to complete the
setting.
Voltage
Under the Sequence function, press
F2 (Edit) button followed by
selecting F3 (Voltage). The setting on
LCD is activated and appears in red
fond color . Use
number pad to set the parameters
directly and then press the F1 (V) or
F2 (mV) button to confirm; or use
arrow keys along with scroll wheel
to complete the setting.
Current
Under the Sequence function, press
F2 (Edit) button followed by
selecting F4 (Current). The setting on
LCD is activated and appears in red
fond color . Use
number pad to set the parameters
directly and then press the F1 (A) or
F2 (mA) button to confirm; or use
arrow keys along with scroll wheel
to complete the setting.
