H3C S5560X-EI Series - Display Vxlan Tunnel

12
Field
Description
• Disabled—The packet statistics feature is disabled for the VSI.
Input statistics
Incoming traffic statistics:
• Octets—Number of incoming bytes.
• Packets—Number of incoming packets.
• Errors—Number of error packets.
• Discards—Number of discarded packets.
Output statistics
Outgoing traffic statistics:
• Octets—Number of outgoing bytes.
• Packets—Number of outgoing packets.
• Errors—Number of error packets.
• Discards—Number of discarded packets.
Gateway Interface VSI interface name.
State
Tunnel state:
• Up—The tunnel is operating correctly.
• Blocked—The tunnel is a backup tunnel. Its tunnel interface is up, but the
tunnel is blocked because the primary tunnel is operating correctly.
• Down—The tunnel interface is down.
Type
Tunnel assignment method:
• Auto—The tunnel was automatically assigned to the VXLAN:
 For an EVPN network, VXLAN tunnels are automatically assigned to
VXLANs.
 For a multicast-mode VXLAN, the tunnel (MTunnel) was automatically
created and assigned to the VXLAN to transmit flood traffic.
• Manual—The tunnel was manually assigned to the VXLAN.
Flood proxy Flood proxy state. This field is not supported in the current software version.
ACs ACs that are bound to the VSI.
Link ID AC's link ID on the VSI.
State
AC state:
• Up.
•
Down
.
Type
Type and traffic match mode of the Ethernet service instance:
• Dynamic (MAC-based)—Dynamic Ethernet service instance in MAC-based
traffic match mode.
• Manual—Static Ethernet service instance in VLAN-based traffic match
mode.
display vxlan tunnel
Use display vxlan tunnel to display VXLAN tunnel information for VXLANs.
Syntax
display vxlan tunnel [ vxlan-id vxlan-id ]
Views
Any view
Predefined user roles
network-admin
